Specifications
Structure
Foundation, Retaining Wall, Columns, Beams & Roof Slab
R.C.C through columns with Framed structures
Cement concrete confirming to grades as per
specifications, drawings and as specified (IS 456 - 2000)
Reinforcement for RCC work with high yield strength
ribbed cold twisted tor steel (HSD) bar of various diameters and grade of steel
as specified by IS code.
External Walls
Masonry Work at all levels using standard size of 600mm X 200mm X 200mm AAC
blocks of thickness 200MM wall.
Internal Walls
Masonry Work at all levels using standard size of 600mm X 100mm X 200mm AAC
blocks of thickness 100MM wall.
External Plastering
Plastering 20 - 25mm thick in two coats with base coat of 16mm thick in CM(1:6)
and top coat of 4mm thick in CM(1:4)
Internal Plastering
Plastering 12 - 15mm thick in two coats with base coat of 8mm thick in CM (1:6)
and top coat of 4mm thick in CM (1:4)
Doors & Windows
Main Door
Wooden Door Frames with Best quality Teakwood frame, 35 mm thick marine flush
(boiling water proof) Door Shutters with both sides Veneer Finished with
melamine polish.
Internal Doors
Wooden Door Frames with Best quality Teakwood frame, 35 mm thick marine flush
flush (boiling water proof) Door Shutters with one side steam beach laminate
& one side Veneer Finished with melamine polish
Windows
UPVC (Unplascticised Poly Vinyl Chloride) Slider Window + mosquito mesh panel
shutter using suitable sections of reputed make
Ventilators
Ventilators with Louvers using suitable sections of reputed make.
Louvers
Powder coated Aluminium Louvers using suitable sections of reputed make
Hardware
Heavy Duty Dorset make or reputed equivalent make to all doors
Painting
External
External plastered surfaces apply Birla putty / Textured paint over two or more
coats of primer and exterior emulsion paint of Asian make or equivalent paints
Internal
Internal plastered surfaces to ceilings apply smooth finish Altek or equivalent
putty finish over two or more coats of primer and Acrylic emulsion paint of
Asian make or equivalent paints
Flooring
Car Park
Best quality Natural stone/Interlocking Pavers/Cement Tiles.
Corridor & Lobby
Best quality Kotah / Kadapa Stone slab of minimum 25mm thick over a bed of CM
(1:4 ).
Straircase
In tread & rise of steps - edge chamfering / half bull nosing of edge and
grooves.
Drawing, Living, Kitchen, Dining & Bed Rooms
Flooring using vitrified tile (600mm x600 mm) and Skirting / borders of 75 mm
with neat groove. reputed make and colour.
Toilets
Flooring with 1st class Ceramic tiles (anti-skid)
of approved make and colour.
Dado using 1st quality glazed / ceramic tiles of
reputed make and colour up to a height of 7'
Premium Sanitary wear (Aqua-do) or equivalent in
all toilets
Jaquar or equivalent bath fitting in all toilets
Geyser provision in all toilets
Master bed room toilet designed to have a separate
shower enclosure
Kitchen
1st quality glazed / ceramic tiles cladding up to a
height of 2' above the kitchen platform
Granite Kitchen platform with stainless steel sink
Provision for washing machine in the utility area
Water Supply
CPVC pipe lines for all water supply lines
Provision for both Municipal & Bore well water
supply with water softener
PVC pipe lines for all sewer lines
Electrical
Concealed Copper wiring in conduits with provision
for adequate electrical points in all rooms & corridors
Premium electrical fittings Clipsol or equivalent
Power supply for each unit and individual meter boards
One Miniature circuit breaker (MCB) for each room
provided at the main distribution board with each unit
Gas Supply
Domestic gas lines using pipe line and separate valve for each unit. Each
connection having individual meter boards
Generator
1 KV Power backup for each flat and complete backup for common areas
Swimming Pool
4.5' depth of swimming pool for adults
3.0' depth of baby pool for children’s
Digital TV
All units will be provided with satellite digital tv connection (TATA-Sky /
Dish TV / Big Tv) Concealed TV wiring in conduits with provision for points in
Living and Master Bedroom
