Specifications
Structure
Framed structure as per
structural designing in reference to geo technical reports and concrete works
using M 20 Grade RMC from approved vendor as per design mix with minimum cement
content of 300 kgs/Cum, affirming to IS - 456, and reinforcement steel detailing
affirming to IS-1786 grade fe415
PCC for flooring and
footings using M 10 Grade RMC from approved vendor as per design mix with
minimum cement content of 180 kgs/Cum
Super Structure
External wall in
8" thick Solid concrete block in CM 1:6, internal and partition wall in
4" Solid concrete block in CM 1:5
Ceiling plastering in
CM 1:4 smooth finish
Internal plastering in
CM 1:6 smooth finish
External plastering in
CM 1:6 sponge finish
Joinery
Main Door Size -
3'6" x 7'0"
Bedroom/Balcony Door
Size - 3'0" x 7'0"
Toilet Door Size -
2'6" x 7'0"
Wood Ghana teak or
equivalent
Main Door Frame section
- 5" x 3", shutter in 35 mm thick skin moulded one side polished, 6
hold fast, 5" SS hinge,10" SS. Tower bolt 2, Magnetic door stopper
and Godrej or equivalent door lock. Bed room Door Frame section - 4" x
3", Shutter in 32 mm thick skin moulded both side painted, 6 nos hold
fast, 5" SS hinge, 8" SS. Tower bolt 2 nos, Magnetic door stopper and
Godrej mortice or equivalent door lock
Toilet Door Frame
section - 4" x 3", Shutter in 32 mm thick skin moulded one side water
proofed painted both sides, 6 nos hold fast, 5" SS hinge, 6" SS Tower
bolt 2 nos and Godrej or equivalent baby latch. Windows in LG huas or
equivalent UPVC windows, french door and ventilators. All windows hung type and
french door slide type. Ventilators louver type and inbuilt 6" exhaust
fan.
Flooring / Dadoo
All rooms in 2' x 2'
vitrified tile in Asian, Nitco, Kajaria, somany or equivalent. Toilet dadoing
10" x 15", flooring 12" x 12" antiskid ceramic tile,
kitchen dado 8" x 12" ceramic tile and utility dado 8" x
12" floor 12" x 12" antiskid tile.
Staircase flooring in
foot grip tile car park flooring in 12" x 12" terracotta tile Kitchen
working platform in 20mm thick black granite with bull nosing.
Electrical
Electrical conducting
in star, Avon last or equivalent, cable in orbit, poly cab, kundan, finolex or
equivalent, modular switches with Anchor roma or equivalent. Living Room - 3
nos 5 amps, 3 nos light point, 1 no fan point, 1 no telephone point, 1 no
television point, 1 no calling bell point. Bedroom - 2 nos 5 amps, 1 no 15
amps, 3 nos light, 1 no fan point, 1 no telephone, 1 no television.
Kitchen/utility - 4 nos 15 amps, 2 nos 5 amps, 1 no chimney point, 1 no water
purifier, 3 nos light, 1 no water motor control. Toilet - 1 no 15 amps, 1 no 5
amps, 1 no light. Carpark - 1 no light, 1 5 amps
External - 3 nos light.
Earthing - 1 no main, 2 no internal. Distribution board in 8 or 12 way, with 6
amps and 10 amps MCB
Meter board concealed
in carpark with safety gadgets
25 sqmm cable for main
EB meter connection
Plumbing/ Sanitary
Internal and External
piping and accessories for water line using 20mm and 30mm CPVC pipe in
Ashirvad, Prince or equivalent
Internal and external
piping and accessories for water line using 110mm and 75mm PVC pipe in
ashirvad, prince or equivalent
Sanitary fixtures in
Parryware Cascade series or equivalent
Faucets in jaguar
continental series or equivalent
2 in 1 wall mixers and
head shower, 1 no health faucet, wash basin pillar cock, kitchen long body
bibcock
3'0" stainless
steel sink with drain board in kitchen
Painting
Internal painting with
Asian paints tractor emulsion or equivalent with 2 coats of putty and 1 coat
water based primer
External painting with
Asian paints or equivalent weather proof paint emulsion 1 coats of putty and 1
coat water based primer
Main door front
polished and other doors enamel painted with 2 coats of oil based putty with 1
coat of primer
MS grills and railings
painted enamel with 1 coat of metal primer or anti corrosive coat
MS Grill / Balcony & Staircase Railing
M S Grill for windows
with minimum 1.6 kgs per sqft
MS railings for
staircase and balcony with minimum 3.2 kgs per Meter
SS with toughened glass
