Specifications
Super Structure
Brick masonry with
first class bricks in cement mortar
Plastering
Internal: 15 mm thick
double coat cement plaster smooth finishing.
External: 12 mm thick double
coat cement plaster with smooth finishing.
Ceiling (External): 20
mm thick double coat sand faced cement plastering.
Flooring
Drawing, Dining,
Living, Foyer & Staircase: Marble slabs / vitrified tiles with 4"
height skirting
Bedrooms & Kitchen:
Marble / vitrified porcelain tiles in size 24" x 24" with 4"
height skirting
Toilets/ Utility area:
Best quality acid resistant antiskid ceramic tiles.
Doors
Main Door: B.T. Wood
door frame & shutter with vision panel one side aesthetically designed with
melamine polishing and designer hard ware of reputed make.
Internal Door: B.T.
wood frame & solid core flush shutter with both sides veneer & polished
of reputed make and standard hardware
Windows: Window frames
&shutters in B.T. Wood painted inside outside with glass panelled glazed
shutters & provision for mosquito mesh, fitted with elegantly designed M.S
grills with standard hardware
Painting
Internal: Smooth finish
with Luppam or equivalent over a coat of primer and top finish
Ceiling : Smooth finish
with Luppam or equivalent over a coat of primer and top finish with two coats
of plastic emulsion paint
External: Texture based
/ External Altek finished paint
Kitchen
Granite platform with
Cerasil sink with both municipal & bore water connection & provision
for fixing aqua guard
Glazed ceramic tile
dado up to 2'0" height, above kitchen plat form
Provision for exhaust
fan and chimney
Upgradable to designer
modular kitchen at extra cost
Utility Wash Area
Glazed ceramic tile
dado up to 3'0" height
Provision for washing
machine, dish washer & wet area for washing utensils
Toilets
Designer make glazed
ceramic tile dado up to 7'0" height toilets
Wash basin with
Hindware or equivalent make
Cascade EWC with health
faucet
Hot and cold wall mixer
with shower
Bath tub provision for
master bedroom
Provision for geysers
in all toilets.
All C.P. fittings are
chrome plated of jaguar's make or equivalent make
Electrical System
Concealed copper wiring
in conduits for lights, fan, plug and power plug points where ever necessary of
Finolex / Anchor make or equivalent make
Power outlets for air
conditioners in all bedrooms
Power outlets for
geysers in all bathrooms
Power plug for cooking
range, refrigerator, micro ovens, mixer & grinder in kitchen
Plug points for
refrigerator, TV & audio systems, etc. where ever necessary
20 AMPS 3 phase supply
for each unit and individual meter boards
Miniature circuit
breakers (MCB) & ELCB for each distribution board of MDS / malingering make
All electrical fittings
of MK / Northwest /Anchor or equivalent make
Split / Window AC
provision for all bed rooms and halls
Water Supply & Sanitary Systems
Water supply points in
kitchen / toilets as required
Municipal water supply
connection provision in kitchen from elevated tank
Hot Water Systems
Solar water heating
system to be provided to individual units at extra cost
Communication System
Telephone points &
TV points in all bedrooms, drawing & dining areas
Telephone cable with
high speed CAT6 cable
Provision for DTH TV
service
Video phone Intercom
facility in all units connecting to Security & amenities
Internet provision in
master bed room and study room using CAT6 cable
Wi Fi near clubhouse
and park
