Specifications
RCC framed structure
with open foundation designed to withstand seismic loads as per structural
design conforming to BIS
Walls using solid
blocks / bricks (clay / fly ash) in cement mortar with reinforcement at sill
level and lintel at 7'0" from floor level
Ceiling height will be
maintained at 9'6” clear from finished floor level
Wall Finishes
Internal walls will be
finished with smooth finished cement plaster, wall care putty coats and premium
emulsion paint
Exterior walls will be
finished with neat cement plaster, white cement coat and weather proof exterior
emulsion paint
Utility / toilet walls
will be finished with designer glazed ceramic tiles of colour and size till
7’0” level as per architect’s concept
Trims, dadoing and
profiles in PVC will be used to protect the edges of the ceramic tiles
Kitchen platform walls
will be finished with ceramic tiles of colour and size up to 3'0" above
the cooking platform
Ceiling surfaces will
be finished with neat cement plaster, white cement coat and Asian ace
Living, dining, kitchen
and bedroom areas will be finished with 24" x 24" vitrified tiles
with 4" high skirting as per architect’s concepts (also with optional
wooden flooring in master bedroom area)
Utility and toilet
areas will be finished with acid proof anti skid ceramic tiles as per
architect’s concept.
Balcony, common areas
and lift lobby will be finished with porcelano / ceramic tiles
Car parking will be
finished with graeno flooring and staircase shall be finished with kota stone
as per architect’s design
Terrace areas will be
finished with proper weathering course
Flooring Joineries
Entrance main door will
be provided with seasoned teak wood frames and 30 mm thick teak wood moulded
panel flush shutter, stainless steel fittings, mortise locks, door eye view
All bedrooms, toilets
and balcony doors will be provided with seasoned country wood frames and water
proof hardcore flush doors with required fittings as per architect’s design
Modular two or three
panel sliding uPVC / country wood window frames and shutters with safety MS
grills will be provided along with mosquito safety nets
Optional french doors
(UPVC / country wood) shall be provided for balcony doors or pent houses
terrace with safety MS grills as per client's requirement by architect’s design
Kitchen
Counter top granite
platform will be finished with 16mm thick granite slab 2'0” wide at a height
2'6” from the finished floor level along with stainless steel single bowl sink
with drain boards and 2 CP long body taps
Provision for exhaust
fan, mixer, grinder, microwave and refrigerator will be provided
Loft will be provided
(optional modular kitchen) as per architect’s design on one side
Bedrooms
A loft will be provided
as per architect’s design on one side.
Concealed conduits for
telephone and cable RF wiring will be provided in master bedroom.
One air conditioner
electrical point will be provided in each bedroom.
Plumbing and Sanitary
All sanitary wares will
be new range IWC / EWC (white or colour) with flush tanks as per architect’s
design and concepts
All CP fittings and
taps (like 2 in 1 wall mixer, shower, health faucet, etc.) will be provided as
per architect’s design
All bathrooms will have
provision for an exhaust fan and geyser connection
Electrical
Phase underground cable
from the onsite transformer power supply and concealed insulated multistrand
copper wires will be provided in all apartments with individual distribution
box having ELCB, MCB's and manual phase change over rotary switches
All switches and
sockets will be provided in metal box and modular switches with cover plates
Power backup shall be
provided for lights, fans and all 5 AMPS switches and sockets only
Elevators
Each block will be
served by a 6 passenger lift with variable voltage variable frequency (V3F) and
automatic rescue device (ARD) technology
Water Proofing & Anti-Termite Treatment
Water proofing
treatment using brush bond technology will be performed for all rest rooms,
utility and other water storing bodies as per architect design
Anti termite treatment
will be performed in six various stages as per BIS for each building of the
project with a guarantee certification of 10 years
Water
Common underground RCC
sump of adequate capacity with hydro pneumatic system for water supply will be
provided
Bore-wells with water
softener plant
Individual R. O.
systems
Sewerage Treatment Plant
STP and common
underground tank provision with manholes, of adequate capacity shall be
provided with provision for recycling the treated water, for flushing and
gardening use
Security
Standalone video door
phone in all apartments
Access controlled entry
into courtyard and each tower block
Material Specifications
Cement: Coromandel /
Chettinad / Penna / Deccan
Steel Rods: Tata Tiscon
/ Vizag / ARS / Udhaya
Paint (Emulsion &
Enamel): Asian Premium / Nippon / ICI
Elevation Exterior
Wall: Asian Ace / Nippon / ICI
Wall Putty & White
Cement: Birla wall care / Asian acrylic / Microplast
Varnish: Sheenlac
Taps and Fittings CP:
Metro / Parryware / Hindware / Cera
IWC / EWC Floor
Closets: Parry ware / Hindware / Cera
Washbasins: Parry ware
/ Hindware / Cera
Plumbing Motor:
Grundfos / Texmo
Plumbing PVC ISI Pipe:
Finolex / Prince / Supreme / Avonplast
Sanitary PVC ISI Pipe:
Finolex / Prince / Supreme / Avonplast
Water Proofing
Chemical: Fosroc Brushbond
Electrical Conduits:
Finolex / Varun / Bajajplast
Main Cable Line:
Universal / Orbit / Polycab
Electrical Wires &
Switches: Finolex / Orbit / Kundan Cab / Polycab
Distribution Board:
Havells / Master / Anchor / HPL
MCB's & Isolators:
Havells / Standard / Anchor / HPL
Rotary Switch: Havells
/ L&T / HPL
Metal Box and Switches:
Anchor / Litaski
Elevators: OTIS /
Johnson
Tiles: Marbonite /
Asian / Orient / Kajarai
UPVC Windows: Fenesta /
Veka / Equivalent
Flush Doors: Diamond /
Prestige / Milton
Mortise Locks: Godrej /
Link
